Galvanized Pipes
Galvanized pipes are products obtained by coating steel, one of the galvanized types, with zinc using the hot-dip technique. However, the properties of the steel to be galvanized must first be examined. Steel can be galvanized if it is rich in phosphorus and silicon. Today, galvanized pipes are frequently preferred due to their superior resistance to precipitation and also because they are economical. Since galvanized pipes are suitable for recycling, it is possible to use them many times.
Dimensions
Galvanized pipe sizes can come in special sizes that are determined as standard and can also be determined according to your wishes and needs. Galvanized pipe weights, which you can have in different sizes and method features according to your usage areas, can also be determined in a personal way.
Usage areas
Galvanized pipes are frequently used in the maritime field, as they are water resistant and rustproof. They can be used in gas lines due to their resistance to temperature changes and humidity. It is also possible to use galvanized pipes in air conditioner production. It is also possible to use in agricultural machinery as it does not rust.
It is possible to use galvanized pipes due to their durability under bridges and superstructures. Galvanized pipes are preferred when constructing railways due to their load resistance and long service life. It is possible to use in the petro-chemical industry.
Galvanized pipes with stainless steel feature are preferred in port construction. It is possible to use galvanized pipes to prevent moisture in warehouses and hangars. It is also possible to use these pipes in the automotive industry.
In addition, galvanized pipe products are often preferred by customers because they are more reasonable in price than stainless steel pipe. Galvanized pipes are used in water pipes because of the clean transfer of drinking water to houses and places.
They ensure that water is transported in a clean manner without producing any harmful substances during the transportation of water. It is also possible to use galvanized pipes in areas required for infrastructure works. In addition, galvanized pipes are preferred because they can last up to 50 years depending on usage.
They are frequently used in electricity poles due to their chemical properties. Galvanized pipes are used in flagpole construction. They are used in areas such as factories and schools as they are durable. In fire protection facilities, they are preferred to ensure that the installations are durable and not calcified for many years. It is also possible to use in ventilation systems.
Qualities
|
Galvanized Products
|
Quality
|
Standard
|
|
Zinc Coated Low Carbon Steel Grades Suitable for Cold Forming Process
|
DX51D+Z
DX52D+Z
|
EN 10346:2015
|
|
Zinc Coated Very Low Carbon Steel Grades Suitable for Cold Forming
|
DX53D+Z DX54D+Z DX56D+Z(1)(3)
DX57D+Z(3)
|
EN 10346:2015
|
|
Zinc Coated Low Carbon Steel Grades Suitable for Cold Forming Process
|
|
CS Type C(1)
CS Type B(1)
ASTM A653M:2015
|
|
Zinc Coated Very Low Carbon Steel Grades Suitable for Cold Forming
|
|
FS Type B(1)
DDS Type A(1)
ASTM A653M:2015
|
|
Zinc Coated High Yield Strength Dual Phase Steel Grades Suitable for Cold Forming Process
|
HCT450X(3)
HCT490X(3)
HCT590X(3)
|
EN 10346:2015
|
|
Zinc Coated Structural Steel Grades Suitable for Cold Forming Process
|
S220GD+Z S250GD+Z S280GD+Z S320GD+Z S350GD+Z S390GD+Z(1) S420GD+Z(1) S450GD+Z(1)(3) S550GD+Z(1)(3)
|
EN 10346:2015
|
|
Zinc Coated Structural Steel Grades Suitable for Cold Forming Process
|
SSGRADE33(1) SSGRADE50(1)
SSGRADE80(1)
|
ASTM A653M:2015
|
|
Zinc Coated Kiln-Hardened Steel Grades Suitable for Cold Forming
|
HX180BD+Z(1)(2)(3) HX220BD+Z(1)(2)(3) HX260BD+Z(1)(2)(3) HX300BD+Z(1)(2)(3) HX340BD+Z(1)(2)(3)
|
EN 10346:2015
|
|
Zinc Coated Very Low Carbon Steel Grades Suitable for Cold Forming
|
HX180YD+Z(1)(2)(3) HX220YD+Z(1)(2)(3) HX260YD+Z(1)(2)(3) HX300YD+Z(1)(2)(3)
|
EN 10346:2015
|
|
Zinc Coated High Strength Low Alloy Steel Grades Suitable for Cold Forming
|
HX260LAD+Z(1) HX300LAD+Z(1) HX340LAD+Z(1) HX380LAD+Z(3) HX420LAD+Z(3) HX460LAD+Z(3) HX500LAD+Z(3)
|
EN 10346:2015
|
1 – It is subject to negotiation over the nearest EN standards at the order stage.
2 – Other issues and/or tolerances not specified here are subject to negotiation at the order stage.
3 – Under development.sNote: Galvanized sheet coating thickness 40 – 350 gr/m²
