Natural Gas Pipeline – HR


Quality : A25 – L175 – L210 – L245 – X42 – L290

Standard : API 5L PSL 1 – API 5L PSL 2 – ISO 3183 PSL 1 – ISO 3183 PSL 2

Outer Diameter : 21,3 – 323,9 mm

Wall Thickness : 1,65 – 13,0 mm

Length : 5,0 – 14,0 m

Kategoriler:

Natural Gas Installation Pipe

What is a Natural Gas Installation Pipe?

Underground and aboveground pipes are used for natural gas transmission. Where these pipes are used, they should provide sufficient resistance to environmental conditions and effects, as well as fulfill the ideal and optimum cost conditions for the need for use. Determining the appropriate conditions has revealed different standards as a result of various experiences and knowledge. Various pipes used in the natural gas industry in our country are used in accordance with certain standards.

Steel pipes used underground and above ground are used in accordance with standards such as TS EN ISO 3183 and equivalent API 5L and ASTM A53 and ASTM A106. Seamless copper pipes are used according to TS EN 1057+A1 standard. Polyethylene pipes are used in accordance with TS EN 1555-1, TS EN 1555-2, TS EN 1555-3+A1 standards. You can access quality documents here.

Bendable hose type pipes are used in accordance with TS EN 15266 and TS 10670 standards. Steel pipes with TS EN ISO 3183 standard, which are used in the natural gas industry you are examining, are equivalent to API 5L standard as their standard content. Pipes reasonable to these equivalent standards provide different quality and specification levels. The material differences within the steel pipes and the differences in the production techniques enable them to reach various quality levels.

Natural gas installation pipes contain different classifications. The positions and requirements of the lines used in the installation after and after the station or service box have caused them to be classified differently.

Features of Natural Gas Pipes

-The wall thickness of natural gas pipes is thicker than the pipes within the scope of TS 301.

-The strength values and chemical content of the pipes are obtained from the most suitable sheet metal for welding.

-Internal burrs are removed and the pipe is completely annealed for stress relief in welded pipes.

-The wall thickness tolerances of natural gas pipes are more sensitive than other pipe types. 1.5% (10% in water pipe)

Pipe connection welds in installations can be screwed or flanged.

-Welding seams are tested by radiographic examination (fluoroscopy) method and ultrasonic examination method so that defective products can be scrapped.

-Hydrostatic pressure is applied to the pipes used in the natural gas installation. In addition, pipes are subjected to magnetic test. In this way, the tightness of the pipe and whether there are any errors in the metallographic structure are checked.

their quality

Steels Suitable for Pipe Manufacturing for Crude Oil and Natural Gas Lines Standard: API 5L 46th Edition-2018 / EN ISO 3183:2019

Chemical Composition (%)

Standard Equivalent

ERDEMİR

Quality No

C(2) max.

Si max

Mn(2)

max.

P max.

S max.

V max.

Nb max.

Ti max.

Other

Carbon(1)

Equivalent (%)

Standard

Specification Level(11)

Quality

CE ııw

max.

CEpcm

max.

API 5L / EN ISO 3183

PSL1

L210 / A

9030

0.22

0.90

0.030

0.030

(9)(10)

API 5L / EN ISO 3183

PSL1

L245 / B

9035

0.26

1.20

0.030

0.030

(3)(8)

(3)(8)

(3)

(9)(10)

API 5L / EN ISO 3183

PSL2

L245N / BN

9036(12)

0.24

0.40

1.20

0.025

0.015

(8)

(8)

0.040

(5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L290 / X42

9042

0.26

1.30

0.030

0.030

(3)

(3)

(3)

(9)(10)

API 5L / EN ISO 3183

PSL2

L290N / X42N

9043(12)

0.24

0.40

1.20

0.025

0.015

0.06

0.05

0.040

(5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL2

L290M / X42M

9044(12)

0.22

0.45

1.30

0.025

0.015

0.05

0.05

0.040

(5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L320 / X46

9046

0.26

1.40

0.030

0.030

(3)

(3)

(3)

(9)(10)

API 5L / EN ISO 3183

PSL2

L320N / X46N

9047(12)

0.24

0.40

1.40

0.025

0.015

0.07

0.05

0.040

(3) (5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL2

L320M / X46M

9048(12)

0.22

0.45

1.30

0.025

0.015

0.05

0.05

0.040

(3) (5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L360 / X52

9052

0.26

1.40

0.030

0.030

(3)

(3)

(3)

(9)(10)

API 5L / EN ISO 3183

PSL2

L360M / X52M

9053(12)

0.22

0.45

1.40

0.025

0.015

(3)

(3)

(3)

(5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L390 / X56

9056

0.26

1.40

0.030

0.030

(3)

(3)

(3)

(9)(10)

API 5L / EN ISO 3183

PSL2

L390M / X56M

9057(12)

0.22

0.45

1.40

0.025

0.015

(3)

(3)

(3)

(5) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L415 / X60

9060

0.26(7)

1.40(7)

0.030

0.030

(4)

(4)

(4)

(9)(10)

API 5L / EN ISO 3183

PSL2

L415M / X60M

9061(12)

0.12(7)

0.45(7)

1.60(7)

0.025

0.015

(4)

(4)

(4)

(6) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L450 / X65

9065

0.26(7)

1.45(7)

0.030

0.030

(4)

(4)

(4)

(9)(10)

API 5L / EN ISO 3183

PSL2

L450M / X65M

9066(12)

0.12(7)

0.45(7)

1.60(7)

0.025

0.015

(4)

(4)

(4)

(6) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL1

L485 / X70

9070

0.26(7)

1.65(7)

0.030

0.030

(4)

(4)

(4)

(9)(10)

API 5L / EN ISO 3183

PSL2

L485M / X70M

9071(12)

0.12(7)

0.45(7)

1.70(7)

0.025

0.015

(4)

(4)

(4)

(6) (9)

0.43

0.25

API 5L / EN ISO 3183

PSL2

L555M / X80M

9080(12)(13)

0.12(7)

0.45(7)

1.85(7)

0.025

0.015

(4)

(4)

(4)

(6) (9)

0.43(7)

0.25

Descriptions

1) % C < if 0.12, C equivalent, CEpcm % = C+(Si/30)+(Mn/20)+(Cu/20)+(Ni/60)+(Cr/20)+(Mo/15)+(V/ 10) It is determined according to the +5B formula.

If B is less than 0.0005% in the casting analysis, the value of B should be ignored in the above formula and the CEpcm formula should be considered zero.

% C > If it is 0.12, C equivalent is determined according to the formula CEııw % = C+(Mn/6)+(Cr+Mo+V)/5+(Ni+Cu)/15. At ERDEMİR, the Carbon Equivalent is stated in the test certificate depending on the casting analysis and It is also guaranteed in product analysis. (PSL2)

2) For every 0.01% decrease in the C value specified in the standard, the Mn value is increased by 0.05%. In this case, the Mn value is; – max 1.65% for 9030, 9031,9035, 9036, 9042, 9043, 9044, 9046, 9047, 9048, 9052, 9053 grades, – max 1% for 9056, 9057, 9060, 9061,9065, 9066 grades, 75, – Maximum 2.00% for 9070, 9071,9080 quality.(PSL1)(PSL2)

3) Nb, V ve Ti miktarlarının toplamı max. %0.15 olmalıdır.(PSL1)(PSL2)

4) Unless otherwise stated, the sum of Nb, V and Ti amounts max. It should be 0.15%.(PSL1)(PSL2)

5) 5- Unless otherwise stated, 9036, 9043, 9044, 9047, 9048, 9053, 9057 grades should be % Cu: max 0.50, % Ni: max 0.30, % Cr: max 0.30, % Mo: max 0.15.(PSL2)

6) Unless otherwise stated, 9061,9066, 9071,9080 grades should be % Cu: max 0.50, % Ni: max 0.50, % Cr: max 0.50, % Mo: max 0.50, in addition, if 9080 quality, % Ni: max 1.00. (PSL2)

7) Unless otherwise stated, these values are valid.(PSL1)(PSL2)

8) Unless otherwise stated, the sum of Nb+V is max. It should be 0.06%. (PSL1)(PSL2)

9) Unless otherwise stated, B is not added and the B amount can be maximum 0.0010%. (PSL1)(PSL2)

10) % Cu: max 0.50, % Ni: max 0.50, % Cr: max 0.50, % Mo: max 0.15.(PSLI)

11) For PSL2 grades, orders over 14.00 mm thickness are subject to negotiation.(PSL2)

12)Products of this quality are produced in full stasis. Therefore, the Al/N ratio is at least 2:1.

13) This quality is produced only in İsdemir facilities.

Steels Suitable for Pipe Manufacturing for Crude Oil and Natural Gas Lines Standard: API 5L-18 / EN ISO3183:2012

Mechanical Properties

Standard Equivalent

ERDEMİR

Quality No’6

Re N/mm2 (kg/mm2)

Rm’1

N/mm(kg/mm2)

R JR t0,5 m

A50′2’ ‘%)

Darbe (3)’4

Heat

KVP

C min.

Standart

Specification

Level(5)

Quality

min.

max.

min.

max.

max.

min.

°C

J

API 5L / EN ISO 3183

PSL1

L210 / A

9030

210

335

36

(21.5)

(34.2)

API 5L / EN ISO 3183

PSL1

L245/ B

9035

245

415

30

(25.0)

(42.3)

API 5L / EN ISO 3183

PSL2

L245N / BN

9036

245

450

415

655

0.93

30

0

40

(25.0)

(45.9)

(42.3)

‘66.7’

API 5L / EN ISO 3183

PSL1

L290 / X42

9042

290

415

30

(29.6)

(42.3)

API 5L / EN ISO 3183

PSL2

L290N / X42N

9043

290

495

415

655

0.93

30

0

40

(29.6)

(50.6)

(42.3)

‘66.7’

API 5L / EN ISO 3183

PSL2

L290M / X42M

9044

290

495

415

655

0.93

30

40

(29.6)

(50.6)

(42.3)

(66.7)

API 5L / EN ISO 3183

PSL1

L320 / X46

9046

320

435

28

(32.6)

(44.4)

API 5L / EN ISO 3183

PSL2

L320N / X46N

9047

320

525

435

655

0.93

28

0

40

(32.6)

(53.6)

(44.4)

(66.7)

API 5L / EN ISO 3183

PSL1

L320M / X46M

9048

320

525

435

655

0.93

28

40

(32.6)

(53.6)

(44.4)

(66.7)

API 5L / EN ISO 3183

PSL1

L360 / X52

9052

360

460

27

(36.7)

(46.9)

API 5L / EN ISO 3183

PSL2

L360M / X52M

9053

360

530

460

760

0.93

27

0

40

(36.7)

(54.1)

(46.9)

(77.5)

API 5L / EN ISO 3183

PSL1

L390 / X56

9056

390

490

25

(39.8)

(50.0)

API 5L / EN ISO 3183

PSL2

L390M / X56M

9057

390

545

490

760

0.93

25

0

40

(39.8)

(55.6)

‘50.0)

(77.5)

API 5L / EN ISO 3183

PSL1

L415 / X60

9060

415

520

24

(42.3)

‘53.1)

API 5L / EN ISO 3183

PSL2

L415M / X60M

9061

415

565

520

760

0.93

24

0

40

(42.3)

(57.6)

‘53.1’

(77.5)

API 5L / EN ISO 3183

PSL1

L450 / X65

9065

450

535

24

(45.9)

‘54.6’

API 5L / EN ISO 3183

PSL2

L450M / X65M

9066

450

600

535

760

0.93

24

0

54

(45.9)

(61.2)

‘54.6’

(77.5)

API 5L / EN ISO 3183

PSL1

L485 / X70

9070

485

570

22

(49.5)

‘58.2’

API 5L / EN ISO 3183

PSL2

L485M / X70M

9071

485

635

570

760

0.93

22

0

68

(49.5)

(64.8)

‘58.2’

(77.5)

API 5L / EN ISO 3183

PSL2

L555M / X80M

9080

555

705

625

825

0.93

22

0

68

(56.7)

(72.0)

‘63.8’

(84.2)

DESCRIPTIONS

1)Although these values are applied to the test samples taken from the pipe in the transverse direction, they are guaranteed in the test samples taken from the hot band in the transverse direction in ERDEMİR production practices.(PSL1)(PSL2)

2)Percent elongation values given in the table d(thickness) > It is valid for 12.7 mm thicknesses. The percent elongation value for thicknesses below this; It is calculated according to the formula A50 (%) = 1940 Axc0-2 / U0-9 (Axc: Cross-sectional area, mm2; U: Minimum tensile strength, N/mm2). (PSL1)(PSL2)

3)PSL2 Impact test is not performed under 6mm for the grades requested in accordance with the specification. It is guaranteed without impact testing for grades 9036, 9043, 9044, 9047, 9048, 9053 with thicknesses of 6 mm and above, but it can be made optionally, and impact testing is performed for grades 9057, 9061,9066, 9071,9080.

4)PSL2 DWTT test is performed in all thicknesses subject to negotiation in the qualities requested in accordance with the specification, at least 85% ductile fracture surface area at 0 °C is guaranteed, and the results are specified separately from the test certificate.(PSL2) results are specified separately from the test certificate(PSL2).

5)Depending on the pipe type, diameter and the direction of the test made from the pipe, there may be differences (decreases or increases) after the tensile tests made from the pipe with the roller.

For this reason, it is recommended that our customers choose the most suitable quality according to the pipe they will produce, considering this situation. ERDEMİR guarantees the mechanical properties specified in the API specifications only in the tests performed in the transverse direction on the hot rolled strip (PSL1)(PSL2).

Usage areas

-Indoor Natural Gas Installation

-Oil pipeline

-Foundation Excavations

– Refineries

Weight Chart - Heavy Section Water and Natural Gas Pipes (DIN 2441)

Nominal diameter

Outer Diameter mm

Wall Thickness mm

With Black Thread Cuff mm

With Galvanized Threaded Coupler kg/m

Black Flat Tip kg/m

Galvanized Flat End kg/m

inç

mm

3/8

10

17.2

2.90

1 03

1.08

1.02

1.07

1/2

15

21.3

3.25

1.46

1.53

1.45

1.52

3/4

20

26.9

3.25

1.91

2.00

1.90

1.99

1

25

33.7

4.05

2.99

3.12

2.97

3.10

1 1/4

32

42.4

4.05

3.87

4.04

3.84

4.01

1 1/2

40

48.3

4.05

4.47

4.67

4.43

4,63

2

50

60.3

4.50

6.24

6.52

6.17

6.45

2 1/2

65

76.1

4.50

8.02

8.38

7.90

8.26

3

80

88.9

4.85

10.3

10.76

10.01

10.06

4

100

114.3

5.40

14.7

15.36

14.40

15.00

5

125

139.7

5.40

18.3

18.7

17.80

18.60

6

150

165 1

5.40

21 8

22.3

21.20

22.20

Weight Chart - Water and Natural Gas Pipes (DIN2440)

Nominal diameter

Outer Diameter mm

Hand Thickness mm

With Black Thread Cuff mm

Galvanized Threaded Coupler kg/m

Black Flat Tip kg/m

Galvanized Flat End kg/m

inç

mm

3/8

10

17.20

2.35

0.86

0.90

0.85

0.90

1/2

15

21.30

2.65

1.23

1.29

1.22

1.27

3/4

20

26.90

2.65

1.59

1.66

1.58

1.65

1

25

33.70

3.25

2.46

2.57

2.44

2.55

1 1/4

32

42.40

3.25

3.17

3.31

3.14

3.28

1 1/2

40

48.30

3.25

3.65

3.81

3.61

3.77

2

50

60.30

3.65

5.17

5.40

5.10

5.33

2 1/2

65

76.10

3.65

6.63

6.93

6.51

6.80

3

80

88.90

4.05

8.64

9.03

8.47

8.85

4

100

114.30

4.50

12.40

13.09

12.10

12.60

5

125

139.70

4.85

16.70

17.50

16.20

16.90

6

150

165.10

4.85

19.80

20.70

19.20

20.10
