Kalite : S235- S355 – S460 – S235 -S355 – S460
Standart : EN 10034 – EU 53-62
Boyut : 100 – 1000 mm.
H(Yükseklik) : 120 – 1008 mm
B (Genişlik) : 106 – 302 mm
T (Kalınlık) : 12,0 – 21,0 mm
Hem demirleri 6 ve 12 mt boyların da satışını yapmaktayız.
Bu demirler bilhassa çelik yapılarda sağladığı mukavemetten dolayı Avrupa’da çok tercih edilmektedir.
Ülkemizde 1999 depreminden sonra mimar ve mühendislerin yeni yeni kullanmaya başladığı başlıca çelik yapı profilidir.
Çelik çatılarda, çelik köprülerde, çelik asma katlarda, çelik binalarda, kullanım kolaylığı ve imalat avantaj sağlarlar.
|
|
ENV 1993-1-1 |
EN 10025-2: 2004 |
EN 10025-4: 2004 |
EN 10225:2001 |
|||||
|
|
|
Yalın eğilme y-y |
|
|
Yalın sıkışma |
|
|
|
|
|
|
S235 |
S355 |
S460 |
S235 |
S355 |
S460 |
|
|
|
|
HE 100 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 120 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 140 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 160 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 180 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 200 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 220 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
? |
? |
|
HE 240 M |
1 |
1 |
– |
1 |
1 |
– |
? |
? |
? |
|
HE 260 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 280 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 300 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 320 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 340 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 360 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 400 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 450 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 500 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 550 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 600 M |
1 |
1 |
1 |
1 |
1 |
1 |
? |
HI |
HI |
|
HE 650 M |
1 |
1 |
1 |
1 |
1 |
2 |
? |
HI |
HI |
|
HE 700 M |
1 |
1 |
1 |
1 |
2 |
3 |
? |
HI |
HI |
|
HE 800 B |
1 |
1 |
1 |
3 |
4 |
4 |
? |
HI |
HI |
|
HE 900 M |
1 |
1 |
1 |
2 |
4 |
4 |
? |
HI |
HI |
|
HE 1000 M |
1 |
1 |
1 |
3 |
4 |
4 |
? |
HI |
HI |
|
Kesit |
Boyut |
G-Brim |
h:Yükseklik |
b: Genişlik |
tw:Gövde Kalınlığı |
tf:Flanş Kalınlığı |
r:İç Köşe Yarıçapı |
1 Çubuk Ağırlığı |
1 Ton İçin Toplam Boy |
|
mm |
Ağırlığı kg/m |
mm |
mm |
mm |
mm |
mm |
kb/12,1m |
m/ton |
|
|
HEM |
100 |
41,8 |
120,0 |
106,0 |
12,0 |
20,0 |
12,0 |
506,0 |
24,0 |
|
HEM |
120 |
52,1 |
140,0 |
126,0 |
12,5 |
21,0 |
12,0 |
630,0 |
19,0 |
|
HEM |
140 |
63,2 |
160,0 |
146,0 |
13,0 |
22,0 |
12,0 |
765,0 |
16,0 |
|
HEM |
160 |
76,2 |
180,0 |
166,0 |
14,0 |
23,0 |
15,0 |
922,0 |
13,0 |
|
HEM |
180 |
88,9 |
200,0 |
186,0 |
14,5 |
24,0 |
15,0 |
1076,0 |
11,0 |
|
HEM |
200 |
103,0 |
220,0 |
206,0 |
15,0 |
25,0 |
18,0 |
1246,0 |
10,0 |
|
HEM |
220 |
117,0 |
240,0 |
226,0 |
15,5 |
26,0 |
18,0 |
1416,0 |
9,0 |
|
HEM |
240 |
157,0 |
270,0 |
248,0 |
18,0 |
32,0 |
21,0 |
1900,0 |
6,0 |
|
HEM |
260 |
172,0 |
290,0 |
268,0 |
18,0 |
32,5 |
24,0 |
2081,0 |
6,0 |
|
HEM |
280 |
189,0 |
310,0 |
288,0 |
18,5 |
33,0 |
24,0 |
2287,0 |
5,0 |
|
HEM |
300 |
238,0 |
340,0 |
310,0 |
21,0 |
39,0 |
27,0 |
2880,0 |
4,0 |
|
HEM |
305 |
177,0 |
320,0 |
305,0 |
16,0 |
29,0 |
27,0 |
– |
– |
|
HEM |
320 |
245,0 |
359,0 |
309,0 |
21,0 |
40,0 |
27,0 |
2965,0 |
4,0 |
|
HEM |
340 |
248,0 |
377,0 |
309,0 |
21,0 |
40,0 |
27,0 |
3001,0 |
4,0 |
|
HEM |
360 |
250,0 |
395,0 |
308,0 |
21,0 |
40,0 |
27,0 |
3025,0 |
4,0 |
|
HEM |
400 |
256,0 |
432,0 |
307,0 |
21,0 |
40,0 |
27,0 |
3098,0 |
4,0 |
|
HEM |
450 |
263,0 |
478,0 |
307,0 |
21,0 |
40,0 |
27,0 |
3182,0 |
4,0 |
|
HEM |
500 |
270,0 |
524,0 |
306,0 |
21,0 |
40,0 |
27,0 |
3267,0 |
4,0 |
|
HEM |
550 |
278,0 |
572,0 |
306,0 |
21,0 |
40,0 |
27,0 |
3364,0 |
4,0 |
|
HEM |
600 |
285,0 |
620,0 |
305,0 |
21,0 |
40,0 |
27,0 |
3449,0 |
4,0 |
|
HEM |
650 |
293,0 |
668,0 |
305,0 |
21,0 |
40,0 |
27,0 |
3545,0 |
3,0 |
|
HEM |
700 |
301,0 |
716,0 |
304,0 |
21,0 |
40,0 |
27,0 |
3642,0 |
3,0 |
|
HEM |
800 |
317,0 |
814,0 |
303,0 |
21,0 |
40,0 |
30,0 |
3836,0 |
3,0 |
|
HEM |
900 |
333,0 |
910,0 |
302,0 |
21,0 |
40,0 |
30,0 |
4029,0 |
3,0 |
|
HEM |
1000 |
349,0 |
1008,0 |
302,0 |
21,0 |
40,0 |
30,0 |
4223,0 |
3,0 |
